The feature is traction invert controls the starting speed direction change and braking which decreased energy consumption have good electric-saving effect.
Product Desc
The feature is traction invert controls the starting speed direction change and braking which decreased energy consumption have good electric-saving effect. Invert have shake-proof damp-proof and dust-proof function the control loop controlled by 2V light current with good safety performance with interlock function when direction change which avoid damage if driver using anti-vehicle braking.
We supply explosion-proof locomotive with CE certification and factory price. Our factory has specialized in mining locomotive for more than 40 years exported to South America and Africa. We are hoping to start business with you soon.
Model | CTY12/6、7、9G(B) | ||
Weight | 12t | ||
Track gauge | 600、762 or 900mm | ||
Traction force | 16.48kN | ||
Max traction force | 29.43kN | ||
Speed | 8.7km/h | ||
Battery device | voltage | 192V | |
capacity | 560Ah | ||
Motor power | 22Kw x 2、30Kw x 2 | ||
Dimensions | Length | 5100mm | |
width | 1050、1212 or 1350mm | ||
Height | 1800mm | ||
Wheel base | 1220mm | ||
Wheel diameter | Φ680mm | ||
Min turn radius | 10m | ||
Controller method | ResistanceIGBT or frequency | ||
Brake method | MechnicalElectricAc frequency |
