2.5 Ton Explosion-proof Locomotive

We provide flameproof locomotive, which is using battery for supply with CE certification. Our factory has specialized in mining locomotive for many years, covering the market of South America and Europe. We are excepting to start business relationshi

CJY10 Ton Underground Mining Trolley Locomotive

​We provide flameproof locomotive, which is using battery for supply with CE certification. Our factory has specialized in mining locomotive for many years, covering the market of South America and Europe. We are excepting to start business relationship with you soon.



Battery-powered locomotives are designed for horizontal rail transport especially in mines and enclosed spaces. They are also intended for use in potentially explosive environment with coal dust and methane in volume up to 1.5 %. They can work on slopes of rail lines up to 35‰ , with track gauge from 500 to 1060 mm, at ambient temperatures from -20°C to +40°C.


Operation video of this battery locomotive



Hot Tags:

Technical Specification

Model CTY2.5/6、7、9G(B)
Dead weight 2.5t
Track gauge 600、762 or 900mm
Traction force 2.55kN
Max traction force 6.13kN
Speed 4.54km/h
Battery device Lithium battery 51.2v 300ah
Lead acid battery 48V330AH
Motor power 3.5kW×1
Dimensions Length 2330mm
width 914、1076 or 1212mm
Height 1550mm
Wheelbase 650mm
Wheel diameter Φ460mm
Min turn radius 5m
Controlling way Resistance or IGBT chopper
Brake way Mechanical brake
