The 5 ton explosion-proof battery locomotive is widely applied in mines which with gas. The locomotive adopts the IGBT controller, which is easy to operate.
The 5 ton anti-explosion battery locomotive is widely applied in mining which with gas. The common equipment with 1 locomotive, 2 anti-explosion lead acid battery and 1 charger.
This type of locomotive could pull about 50 ton ores at the slope of 3‰ , it will be a good choice for small or middle mines.
Below is our operation video on South America
Operation video
←No Information
 |
Model | CTY5/6、7、9G(B) | ||
| Total-weight | 5t | |||
| Track gague | 500、600、762 or 900mm | |||
| Tracktion force | 7.06kN | |||
| Max traction | 12.26kN | |||
| Speed | 7km/h | |||
| Battery device | Voltage | 90V | ||
| Capacity | 385Ah | |||
| Motor power | 7.5 kW×2 | |||
| dimensions | Lenght | 3170mm | ||
| Width | 920、1082 or 1220mm | |||
| Height | 1550mm | |||
| Wheel base | 850mm | |||
| Wheel diameter | Φ520mm | |||
| Min turn radius | 6m | |||
| Controlling way | Resistence or IGBT | |||
| Brake way | Mechnical brake or hydraulic | |||
