1.5ton underground mining battery locomotive

Date:2021-08-04

The 1.5-ton mining lithium battery electric locomotive uses lithium power or lead-acid power, with a traction force of ≤15 tons, which is the best choice for small mine transportation.

Below is the specification of 1.5 ton battery locomotive

Model		CTY1.5/6、7、9G(B)
Dead Weight		1.5t
Track gauge		600、762,900mm or required
Traction force		5kN
Traction force/h		2.75kN/h
Speed		4.5km/h
Rated Voltage		60V
Capacity		600AH
Motor		1.5kW×1
Dimensions	Length	1880mm
	Width	800mm
	Height	1550mm
	Wheel base	550mm
Minimum turning radius		4m
Controller Way		IGBT
Brake Way		Mechanical and electric
