The 45kw DK812 motor is specially designed for Russian mining electric locomotives, and is suitable for K-10 and K-14 overhead electric locomotives.
The 45kw DC motor is designed to operate at altitudes from -1500m to +2000m above sea level, with an ambient temperature of +35° to -40°C; 98% relative humidity with moisture condensation at 35°C; in the case of methane, the environment is explosion proof , and does not contain corrosive gases and vapors, the concentrations of which would damage the protective coating and insulation of current-carrying parts; the maximum dust content of mine dust is 250 cubic meters.
Structure and Working Principle : Brush
Certification : ISO9001
Brand : Yutong
Power : 52kw
Voltage : 550V
Current : 106A
Rotating Speed : 1300
Max. Current : 212A
Max.Rotating Speed : 2800
Structural Type : Horizontal
Working Rating : S2-60min
Excitation Rate : 100%
Insulation Grade : F
Cooling Type : IC40
Weight : 610kg
Certificate : ISO, Ma, Ka
Usage : Mining Electric Locomotive
Transport Package : Wooden Package
Trademark : Yutong
Origin : Xiangtan, China
Production Capacity : 2000 Set /Year
