We have specialized in mining locomotive for many years, could offer flameproof mining locomotive with CE certification and factory price. Covering the market in Africa and South America, we are excepting to become your long-term partner in China.
Product introduction
3 ton Flameproof Locomotive is special customized type for the high altitude area mines, with the insulation of H level. It has the advantages of easy-operation, high starting torque, strong traction force and carrying capacity.
Operation video:
| Model | CTY3/6、7、9G(B) | ||
| Dead weight | 2.5t | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 2.55kN | ||
| Max traction force | 6.13kN | ||
| Speed | 4.54km/h | ||
| Battery device | Lithium battery | 51.2v 300ah | |
| Lead acid battery | 48V330AH | ||
| Motor power | 3.5kW×1 | ||
| Dimensions | Length | 2330mm | |
| width | 914、1076 or 1212mm | ||
| Height | 1550mm | ||
| Wheelbase | 650mm | ||
| Wheel diameter | Φ460mm | ||
| Min turn radius | 5m | ||
| Controlling way | Resistance or IGBT chopper | ||
| Brake way |
Mechanical brake |
||
