We provide flameproof locomotive with factory price. We have devoted ourselves in mining locomotive for many years covering the market in South America and Europe. We are looking forward to start business with you soon.
Main features
1. Simple structure in linear type easy in installation and maintain.
2. Adopting advanced world famous brand components in pneumatic parts electric parts and operation parts.
3. High pressure double crank to control the die opening and closing.
We provide flameproof locomotive with factory price. We have devoted ourselves in mining locomotive for many years covering the market in South America and Europe. We are looking forward to start business with you soon.
Our advantage:
1. Price: we are factory it will be best price.
2. Production: fast production ability.
3. Technical Support.
Model | CTY5/6、7、9G(B) | |||
Total-weight | 5t | |||
Track gague | 500、600、762 or 900mm | |||
Tracktion force | 7.06kN | |||
Max traction | 12.26kN | |||
Speed | 7km/h | |||
Battery device | Voltage | 90V | ||
Capacity | 385Ah | |||
Motor power | 7.5 kW×2 | |||
dimensions | Lenght | 3170mm | ||
Width | 920、1082 or 1220mm | |||
Height | 1550mm | |||
Wheel base | 850mm | |||
Wheel diameter | Φ520mm | |||
Min turn radius | 6m | |||
Controlling way | Resistence or IGBT | |||
Brake way | Mechnical brake or hydraulic |
