Introduction of ZWY50 multifunctional mine mucking machine

Date:2021-11-10

The ZWY50 multifunctional mine mucking machine is a new type of loader developed to improve labor intensity and work efficiency. The machine can directly transport rocks to the conveyor belt. The machine adopts full hydraulic control mode, which is simple and convenient to operate. The gantry frame of the machine is detachable and non-cut, which is convenient for installation in the well. In addition, the height of the rear unloading can be adjusted according to the customer's own needs. The machine is equipped with an adventure device to solve the danger of manual exploration. This machine can be used in a cave below 2.2 meters, and the loading capacity per hour is between 40-60m³.

Dimensions (L×W×H): 5000×1350×1500(mm)
Loading capacity: ≤50(m³/h)
Total Weight: 2700(kg)
Digging width: 2200(mm)
Digging height: 1600(mm)
Digging depth: ≤500(mm)
Gradeability: ≤5°(Hard ground
Adaptation dimension: 1.8×1.8(m)
Digging distance: ≥1300(mm)
Minimum turning radius: ≤5°
Unloading height: 1200(mm)(Can be heightened)
Unloading distance: 1300(mm)(Can be lengthened)
Motor Power: 11(kw)
Walking speed: 1.45(km/h)
Maximum material passing size: 500×350(mm)
Wheelbase: 1300(mm)
Diameter of breaking hammer: 45(mm)
Breaking hammer working flow: 20-40(L/min)
Breaking hammer impact frequency: 700-1200(bmp)
Transmission Type: Belt Transmission
