What are the model parameters of Mgc1.7-6 Fixed Mine Car?

Date:2021-11-17

The Mgc1.7-6 fixed mine car box is fixedly connected with the frame, and the mine cart must be turned over and unloaded with a dumper. Its basic composition is the carriage, the frame, the buffer, the coupling and the walking mechanism.
The frame is a metal structure that can withstand the traction, braking force, collision force between the mine cars and the impact force of the steel rail. Buffers are installed at both ends of the frame to ease the impact between the two cars.
The coupler is a part connecting the locomotive and the mine car. Commonly used are the bolt chain link and the rotary chain. The large mine car adopts the automatic coupler with the buffer function.
The traveling mechanism is composed of two wheelsets consisting of four wheels and two axles.
When the total of mine carts and materials exceeds 20 tons, the number of wheel sets should generally be increased. For mine cars with more than two wheelsets, in order to facilitate the formation of a car with a turntable through the bends, this kind of car is called a bogie.
Volume: 1.1 cubic meter
Load capacity: 1 t
Max. Loading capacity: 1.8 t
Gauge: 600 mm
External dimension
L: 2000 mm
B: 880 mm
H: 1150 mm
Wheel base: 550 mm
Wheel diameter: 300 mm
Traction height: 320 mm
Allowable traction: 60 KN
Minimum plane running radius: 9 m
