YUTONG factory supply high quality electric mining trolley locomotive with competitive price. We specialized in mining locomotive for many years exported lots of locomotive to South America and Europe in these years. We are looking forward to start business relationship with you.
Trolley locomotives are designed for horizontal rail transport especially in mines and enclosed spaces to the non-hazardous areas without explosion risks. They can work on slopes of rail tracks to 35‰ with track gauge from 500 to 1060 mm at ambient temperatures from -10 to 40 °C.
 |
Model | CJY3/6、7、9G(B) | |
| Weight | 3 ton | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 5.74kN | ||
| Max traction force | 7.36kN | ||
| Speed | 7.5km/h | ||
| Dc voltage | 250V | ||
| Motor power | 6.5kW×2/ 7.5kw*2 | ||
| Dimensions | Length | 2750mm | |
| Width | 940、1082 or 1220mm | ||
| Height | 1550mm | ||
| Wheelbase | 850 mm | ||
| Wheel diameter | Φ520 mm | ||
| working height of Pantograph | 1800~2000mm | ||
| Min turn radius | 6m | ||
| Control method | Resistance or IGBT | ||
| Brake method | Mechnical or hydraulic | ||
