MGC3.3 Fixed Mine Car, 3 ton loading capacity mining wagonsThe MGC3.3 is a large, heavy-duty fixed mine car that is designed for the most demanding mining applications. With a capacity of 3.3 cubic meters and a load capacity of 3 tons, the MGC3.3 can transport even the heaviest loads with ease.
MGC3.3 Fixed Mine Car, 3 ton loading capacity mining wagons
The MGC3.3 is a large, heavy-duty fixed mine car that is designed for the most demanding mining applications. With a capacity of 3.3 cubic meters and a load capacity of 3 tons, the MGC3.3 can transport even the heaviest loads with ease.
Features:
Extra-large capacity for transporting the heaviest loads
Robust chassis for long-lasting durability
Reduced maintenance costs
Enhanced safety and reliability
Shipment and one site details
←MGC1.7 Fixed Mine Car, 1.5 ton loading capacity mining wagons
KFU0.55 Bucket-tipping Mine Car, 1.3 ton loading capacity mining wagons→
| Fixed Mine Car | |||||||||||||
| Model | Volume(m3） | Capacity（T) | Max. Load(T) | Gauge(mm) | Wheel Base(mm) | Wheel Diameter (mm) | Traction force(KN) | Traction Height(mm) | Overall Size(LxWxH) | Weight(≤kg) | |||
| MGC1.7-6 | 1.7 | 1.5 | 2.7 | 600 | 750 | 300 | 60 | 320 | 2400x1050x1200 | 720 | |||
| MGC1.7-9 | 1.7 | 1.5 | 2.7 | 900 | 600 | 350 | 60 | 320 | 2100x1150x1300 | 970 | |||
| MGC1.1-6 | 1.1 | 1 | 1.8 | 600 | 550 | 300 | 60 | 320 | 2000x880x1150 | 610 | |||
| MGC3.3-9 | 3.3 | 3 | 5.3 | 900 | 1100 | 350 | 60 | 320 | 3450x1320x1300 | 1320 | |||
