Flameproof Mine Locomotive LED Lamp

This Anti-explosive mine locomotive lamps ia applied in the mining explosion-proof battery locomotive.

CJY10 Ton Underground Mining Trolley Locomotive

 This Anti-explosive mine locomotive lamps ia applied in the mining explosion-proof battery locomotive, which is suitable for those places with gas.

Product advantages:

Safe and maintenance-free; LED light source has no filament and anti-vibration.

Features:

1. The light source can be changed to a red LED, which can be assembled into a high beam as a signal lamp, a low beam as a headlight, or a low beam as a signal lamp, or a two-way illumination, and the far and near lights can be freely changed. It needs to be produced according to customer needs.

2. Long service life, the theoretical service life is more than 50,000 hours.

3. Energy saving and environmental protection, the main light source power of this lamp is only 9W and 18W, and the brightness is 5-7 times that of the same wattage incandescent lamp.

4. The working temperature of the light source is low, and the surface temperature is only about 50 degrees.

5. Wide voltage circuit design, saving voltage regulating resistor or straight converter.

Specification Voltage Power Luminous flux Range of use Weight(kg)
DGY9/24L(A)  DC24V  9W  450-630LM 12V-48V   8kg
DGY9/36L(A)  DC36V 9W  450-630LM 12V-48V  8kg
DGY9/48L(A)  DC48V 9W  450-630LM 24V-96V  8kg
DGY9/127L(A  DC127V 9W  450-630LM 96V-250V  8kg
DGY18/24L(A)  DC24V  18W  450-630LM 12V-48V   8kg
DGY18/36L(A)  DC36V 18W  450-630LM 12V-48V  8kg
DGY18/48L(A)  DC48V 18W  450-630LM 24V-96V  8kg
DGY18/127L(A)  DC127V 18W  450-630LM 96V-250V  8kg
