Z-17 Electric Mucking Machine Loader

The Electric rock loader can be used in the field of metal mines(Gas free), drifting, ore loading, especially in some dangerous place, which have the advantages of safer working environment, enhancement in efficiency, enhancement in integrated effects

CJY10 Ton Underground Mining Trolley Locomotive
Product Description
The Electric rock loader can be used in the field of metal mines(Gas free), drifting, ore loading, especially in some dangerous place, which have the advantages of safer working environment, enhancement in efficiency, enhancement in integrated effects.
It have normal type and remote type can be choosed.

Operation Video



Hot Tags: Z-17 Electric Mucking Machine Loader,China, manufacturers, suppliers, factory, customized, price
Specification
Model Z-17AW Z-20AW Z-30AW ZQ-26
Loading capacity m³/h 20-30 30-40 50-60 40-50
Loading area m³ 0.17 0-20 0.3 0.26
Loading width m 1.7 2 2.2 2.7
Track gauge mm 500,600,762 or 900
Power Motor Motor Motor Wind motor
Walking power kw 10.5 10.5 15 10.5
Lifting bucket power KW 10.5 13 15 15
Unloading height mm 10.5 1360 1370 1250
Dimension mm Length  2120 2480 2620 2440
Width 1011 1380 1320 1380
Height 1920 1460 1545 1500
Weight 3760 3700 4600 2700
