Home > Product > Battery locomotive > Battery Powered Mine Locomotive
We could offer highly-strength battery powered mine locomotive with CE certification. Covering the market in South America and Europe we are hope to start stable and long-term business relationship with you.
About Us
We have CE Certificate SGS Product Certificate ISO9000 Quality Control Certificate and BV Supplier Certificate; our machine had won much good reputation through its quality and nice performance. Nowadays our products have been exported to 127 countries and regions over the world.
←No Information
Technical Specification
 |
Model | CTY2.5/6、7、9G(B) | ||||
| Dead weight | 2.5t | |||||
| Track gauge | 600、762 or 900mm | |||||
| Traction force | 2.55kN | |||||
| Max traction force | 6.13kN | |||||
| Speed | 4.54km/h | |||||
| Battery device | Lithium battery | 51.2v 300ah | ||||
| Lead acid battery | 48V330AH | |||||
| Motor power | 3.5kW×1 | |||||
| Dimensions | Length | 2330mm | ||||
| width | 914、1076 or 1212mm | |||||
| Height | 1550mm | |||||
| Wheelbase | 650mm | |||||
| Wheel diameter | Φ460mm | |||||
| Min turn radius | 5m | |||||
| Controlling way | Resistance or IGBT chopper | |||||
| Brake way | Mechanical brake | |||||
