This 8 ton mining diesel dumper truck is designed to meet the specific requirements of underground mining operations. The explosion-proof design ensures safe operation in hazardous environments, while the powerful diesel engine provides the necessary power to haul large loads in confined spaces. This rugged truck is equipped with advanced safety features to protect the operator and maximize uptime.
8 ton mining diesel dumper truck with Four-wheel drive
This 8 ton mining diesel dumper truck is designed to meet the specific requirements of underground mining operations. The explosion-proof design ensures safe operation in hazardous environments, while the powerful diesel engine provides the necessary power to haul large loads in confined spaces. This rugged truck is equipped with advanced safety features to protect the operator and maximize uptime.
Video
Shipment and site details
| Load capacity | 4 ton | 5 ton | 6 ton | 8 ton | 10 ton | 12 ton |
| Fuel type | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Motor model | Changchai 490 | Yunnei 490 | Yunnei 490 | Yunnei 4102 | Yunnei 4102 | Yunnei 4105 |
| Motor power | 46KW (63 HP) | 46KW (63 HP) | 46KW (63 HP) | 81KW (110 HP) | 81KW (110 HP) | 90KW (122 HP) |
| Gearbox model | 530 (12-speed) | 530 (Twelve high and low speed gears) | 530 (Twelve high and low speed gears) | 546 (Twelve high and low speed gears) | 546 (Twelve high and low speed gears) | 545 (Twelve high and low speed gears) |
| Rear axle | SL176T | DF1069 | DF1069 | DF1092 | DF1092 | DF1098D |
| Front axle | SL175T | SL178 | SL178 | SL2059 | SL2059 | SL450 |
| Braking system | Air Brake | Air Brake | Air Brake | Air Brake | Air Brake | Air Brake |
| Rear wheel track | 1450mm | 1630mm | 1630mm | 1800mm | 1800mm | 2150mm |
| Front wheel track | 1450mm | 1630mm | 1630mm | 1800mm | 1800mm | 1900mm |
| Wheelbase | 2400mm | 2400mm | 2620mm | 2620mm | 2650mm | |
| Chassis | Main beam: Height 120mm * Width 60mm * Thickness 8mm, Bottom beam: Height 80mm * Width 60mm * Thickness 6mm | Main beam: Height 120mm * Width 60mm * Thickness 8mm, Bottom beam: Height 80mm * Width 60mm * Thickness 6mm | Main beam: Height 120mm * Width 60mm * Thickness 8mm, Bottom beam: Height 80mm * Width 60mm * Thickness 8mm | Main beam: Height 140mm * Width 60mm * Thickness 10mm, Bottom beam: Height 80mm * Width 60mm * Thickness 8mm | Main beam: Height 200mm * Width 60mm * Thickness 10mm, Bottom beam: Height 80mm * Width 60mm * Thickness 8mm | |
| Unloading method | Rear unloading | Rear unloading, double 800mm hydraulic jacks | Rear unloading, double 800mm hydraulic jacks | Rear unloading, double 110mm hydraulic jacks | Rear unloading, double 110mm hydraulic jacks | Rear unloading, double 110mm*950mm hydraulic jacks |
| Front tire model | 650-16 steel wire tire | 700-16 mining tire | 700-16 mining tire | 750-16 mining tire | 825-16 mining tire | 825-16 mining tire |
| Rear tire model | 700-16 steel wire tire (dual) | 700-16 mining tire (double tire) | 700-16 mining tire (double tire) | 750-16 mining tire (double tire) | 825-16 mining tire (double tire) | 825-16 mining tire (double tire) |
| D imensions | L*W*H : 3950mm*1450mm*1330mm | L*W*H : 4900mm*1630mm*1400mm | L*W*H : 4900mm*1630mm*1400mm | L*W*H : 5200mm*1800mm*1750mm | L*W*H : 5400mm*1800mm*1750mm | L*W*H : 5100mm*2150mm*1750mm |
| Cargo dimensions | L*W*H : 2400mm*1330mm*450mm | L*W*H : 3100mm*1600mm*500mm | L*W*H : 3100mm*1600mm*500mm | L*W*H : 3400mm*1750mm*750mm | L*W*H : 3600mm*1750mm*750mm | L*W*H : 3400mm*2100mm*750mm |
| Cargo plate thickness | Bottom 8mm, Side 5mm | Bottom 10mm, Side 5mm | Bottom 10mm, Side 5mm | Bottom 10mm, Side 5mm | Bottom 10mm, Side 5mm | Bottom 10mm, Side 6mm |
| Steering wheel | Hydraulic Power Steering | Hydraulic Power Steering | Hydraulic Power Steering | Hydraulic Power Steering | Hydraulic Power Steering | Hydraulic Power Steering |
| Cargo volume | 1.6 m3 | 2.2 m3 | 2.2 m3 | 4.3 m3 | 4.7 m3 | 5 m3 |
