12 Ton Flameproof Locomotive

The feature is traction invert controls the starting speed direction change and braking which decreased energy consumption have good electric-saving effect.

CJY10 Ton Underground Mining Trolley Locomotive

12 Ton Flameproof Locomotive

Product Description:

The feature is traction invert controls the starting speed direction change and braking which decreased energy consumption have good electric-saving effect. Invert have shake-proof damp-proof and dust-proof function the control loop controlled by 2V light current with good safety performance with interlock function when direction change which avoid damage if driver using anti-vehicle braking.

We supply explosion-proof locomotive with CE certification and factory price. Our factory has specialized in mining locomotive for more than 40 years exported to South America and Africa. We are hoping to start business with you soon.




Shipment and one site details

8o12t battery locomotive 1.jpg







Model CTY12/679G(B)
Weight 12t
Track gauge 600762 or 900mm
Traction force 16.48kN
Max traction force 29.43kN
Speed 8.7km/h
Battery device voltage 192V
capacity 560Ah
Motor power 22Kw x 230Kw x 2
Dimensions Length 5100mm
width 10501212 or 1350mm
Height 1800mm
Wheel base 1220mm
Wheel diameter Φ680mm
Min turn radius 10m
Controller method ResistanceIGBT or frequency
Brake method MechnicalElectricAc frequency



8o12t battery locomotive 2.jpg

shipment and site 13.jpg
