Bucket-tipping mine car/Wagons

The bucket-tippingmine car /Wagons is a narrow-gauge railway transportation vehicle for transporting coal ore ballast and other bulk materials in the mine. Generally it must be tractby a locomotive or a winch. According to different structures and

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
The bucket-tipping mine car /Wagons is a narrow-gauge railway transportation vehicle for transporting coal ore ballast and other bulk materials in the mine. Generally it must be tract by a locomotive or a winch.
According to different structures and unloading methods they are divided into four categories: bucket-tipping mine car fixed mine car single-side curved rail dumping mine car and bottom-dumping mine car.

The main features of the bucket-tipping mine car:
The bucket-tipping mine car does not need any auxiliary facilities can automatically flip left and right is flexible and light.
The frame is a metal structure which can withstand the traction force ultromotivity collision force between mine cars and rail impact force;
This type of mine car has the advantages of firm structure beautiful appearance reliable performance flexible and stable operation etc.
The frame of the mine car adopts a riveted welding structure which reduces the influence of gravity on the mine car and increases the service life of the mine car.
The mine car is guaranteed to run smoothly whether in a bend or a straight.
This series of mining wagon are widelyused for underground and surface coaltransportation in coal minesiron ore phosphate mines etc. It iscommonly used transportation equipment such as coal mines.


Operation video


Hot Tags:

←Mining Wagons / Rail Wagons for transportation

MGC Series Fixed Mine Car→

Related Product
Technical performance table of bucket-tipping mine car
Model Volume(m³）  Load(T) Gauge(mm) Wheel Base(mm) Wheel Diameter (mm) Traction force (KN) Traction Height(mm) Overall Size(LxWxH) Weight(≤kg)
KFU0.55-6 0.55 1.3 600 500 300 60 320 1552*850*1150 700
KFU0.75-6 0.75 1.88 600 600 300 60 320 1700*980*1250 740
KFU1.0-6 1 2 600 650 300 60 320 1910*1070*1320 760
KFU1.2-6  1.2 3 600 650 300 60 320 2060*1150*1300 610
