The 5 ton explosion-proof battery locomotive is widely used in mines that with gas. The locomotive adopts the IGBT controller or AC controller, which is easy to operate. It could pull about 50 ton ores at the slope of 3 , it will be a good choice for
The 5 ton explosion-proof battery locomotive is widely used in mines that with gas. The locomotive adopts the IGBT controller or AC controller, which is easy to operate. It could pull about 50 ton ores at the slope of 3‰ , it will be a good choice for small or middle mines.
The quality of the our locomotive is in full compliance with the national standard requirements by using high-quality steel plates.
Strict assembly technology ensures that the locomotive leather is durable and reliable.
Special rust removal process on the surface plus multi-layer anti-corrosion coating, more anti-corrosion, suitable for
high-corrosion and high-humidity environment in underground.
Operation Video
Technical specification table
 | Model | CTY5/6、7、9G(B) | ||
| Total-weight | 5t | |||
| Track gague | 500、600、762 or 900mm | |||
| Tracktion force | 7.06kN | |||
| Max traction | 12.26kN | |||
| Speed | 7km/h | |||
| Battery device | Voltage | 90V | ||
| Capacity | 385Ah | |||
| Motor power | 7.5 kW×2 | |||
| dimensions | Lenght | 3170mm | ||
| Width | 920、1082 or 1220mm | |||
| Height | 1550mm | |||
| Wheel base | 850mm | |||
| Wheel diameter | Φ520mm | |||
| Min turn radius | 6m | |||
| Controlling way | Resistence or IGBT | |||
| Brake way | Mechnical brake or hydraulic | |||
