Our factory have large production ability, could offer high quality battery locomotive with huge tonnage. We have specialized in mining locomotive many years and exported to South America and Europe, we are looking forward become your long-term partne
Our factory have large production ability, could offer high quality battery locomotive with huge tonnage. We have specialized in mining locomotive many years and exported to South America and Europe, we are looking forward become your long-term partner in China.
Application
Locomotive is used for hauling mine cars, transporting mineral or equipments and personnel in underground mine with explosive mash gas and ash, it also can be used in surfaced mine, tunnel, and factory. As a conveyance, locomotive runs on track.
Locomotive Avantage Please Click: Locomotive Advantages.| Type | CTY15/6、7、9G(B) | ||
| Total weight | 15t | ||
| Track gague | 600、762 or 900mm | ||
| Traction | 18.47kN | ||
| Max traction | 36.18kN | ||
| Speed | 9.6km/h | ||
| Battery device | Voltage | 256V | |
| Capacity | 560Ah | ||
| Motor power | 30Kw x 2 | ||
| Dimensions | Length | 5200mm | |
| Width | 1500mm | ||
| Height | 1920mm | ||
| Wheel base | 1400mm | ||
| Wheel diameter | Φ680mm | ||
| Min curve radius | 15m | ||
| Controlling way | IGBT OR AC Converter | ||
| Brake way | Mechnical or air brake | ||
