Home > Product > Battery locomotive > Battery Powered Mine Locomotive
The engine casing of our locomotive is processed by seamless steel tubes, specially developed for mine conditions, resistance to moisture and earthquakes.
Product Advantage
The engine casing is processed by seamless steel tubes, specially developed for mine conditions, resistance to moisture and earthquakes.
The steel wheel is cast in manganese steel, wear resistant and durable.
We have devoted ourselves to mining locomotive for many years, could offer battery powered mining locomotive with good mobility and factory price.
Quick information of 3 ton battery locomotiveTechnical Specification
| Model | CTY3/6、7、9G(B) | ||
| Dead weight | 3t | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 2.55kN | ||
| Max traction force | 6.13kN | ||
| Speed | 4.54km/h | ||
| Battery device | Lithium battery | 51.2v 300ah | |
| Lead acid battery | 48V330AH | ||
| Motor power | 4.5kW×1 | ||
| Dimensions | Length | 2330mm | |
| width | 914、1076 or 1212mm | ||
| Height | 1550mm | ||
| Wheelbase | 650mm | ||
| Wheel diameter | Φ460mm | ||
| Min turn radius | 5m | ||
| Controlling way | Resistance or IGBT chopper | ||
| Brake way |
Mechanical brake |
||
