6 Ton Battery Locomotive is specifically designed for South AmericaAdhesive / total weight (t)： 6<br>Traction (KN): 7.06<br>Max. Traction (KN): 12.26<br>Battery Voltage (V): 90
Battery Powered Mine Locomotive is an important transportation tool for long-distance transportation of mine horizontal roadway and plays an important role in coal transportation and auxiliary transportation in mine. It has the advantages of low cost large transportation capacity convenient operation and use and non-working reserve system.
The mine electric locomotive consists of mechanical part and electrical part. The mechanical part includes: frame wheelset bearing box spring bracket braking device sanding device connecting buffer device etc.
The electrical part includes: DC series motor controller resistance box pantograph air automatic switch or flameproof plug battery (battery electric locomotive).
Locomotive Avantage Please Click: Locomotive Advantages.
 |
Model | CTY6/6、7、9G(B) | ||
| Total-weight | 6t | |||
| Track gague | 500、600、762 or 900mm | |||
| Tracktion force | 7.06kN | |||
| Max traction | 12.26kN | |||
| Speed | 7km/h | |||
| Battery device | Voltage | 90V | ||
| Capacity | 385Ah | |||
| Motor power | 7.5 kW×2 | |||
| dimensions | Lenght | 3170mm | ||
| Width | 920、1082 or 1220mm | |||
| Height | 1550mm | |||
| Wheel base | 850mm | |||
| Wheel diameter | Φ520mm | |||
| Min turn radius | 6m | |||
| Controlling way | Resistence or IGBT | |||
| Brake way | Mechnical brake or hydraulic | |||
