The 15ton battery locomotive could be divided into an-explosion one and normal one it could be applied in the mining construction or tunnel construction.
The 15ton locomotive is specially designed for constructions of large tunnel subways and water diversion works. It is applied of speed control of resistors. Its raking types include hand wheel switch braking resistor braking and air damping. V-shape rubber damps are used on the locomotive in order to bear vibration and impact from lengthways vertical and transverse directions. Main features include: strong traction force and carrying capacity and high speed.
Quick Information of 15ton battery locomotive
Product Name: 15 Ton Electric Mining Battery Locomotive |
Fuel Type: Electric |
Brand Name: YuTong |
Traction mode power: 30x2 |
Dimensions (L x W x H) (mm): 5220*1400*2140mm |
Speed (km/h): 9.6km/h |
Application: Mining; Subway Tunnel Locomotive |
Rail gauge: 600/762/900mm or customized |
Place of Origin: Xiangtan China (Mainland) |
Rated voltage: 256V |
Advantages: Strong traction force |
Braking type: Mechanical and Electric or air brake |
Service: OEM/ODM |
Speed control: Resistor or AC or IGBT |
Operation Video
This 15ton battery locomotive could also choose the lithium battery as a optional.
4 Main advantages of our Lithium battery (More about our advantages please click on the red words- Locomotive Advantages)
1. No need to counterweight
2. No.3 communication management system wireless BMS system
3. Intelligence operation display
4. Support custom charger could custom charger time according your requirements
Input voltage range is 320V-450V not easy to burn electronic components IP54 for charger more meet required.
