4 Ton Electric Trolley Locomotive Of Ukraine Type

4 ton Electric locomotive is a special type design for Russia,Kazakhstan,also the other country of Five Central Asian Countries.

CJY10 Ton Underground Mining Trolley Locomotive

The 4 ton Electric Trolley locomotive is a special type design for Russia,Kazakhstan,also the other country of Five Central Asian Countries, we design this trolley locomotive according to the Ukraine Type.

We could design the shape according to your requirement, such as the middle driver cab, large powerful motors, and firm frame structure.

Basic Requirement of 4 ton Electric Trolley locomotive:

Voltage: 250V or 550V

Track Gauge: 600,750,762,900

Controller method: Resistance, IGBT or AC frequency control

Position of Driver Cab: middle or the single-end

4 ton Electric Trolley Locomotive has simple structure,high electricity efficiency, low transportation cost, few failures, and easy to maintain.

Locomotive Avantage Please ClickLocomotive Advantages.

4.Video


Hot Tags: 4 ton electric trolley locomotive of ukraine type, China, manufacturers, suppliers, factory, customized, price
Model CJY4/679G(B)
Weight 4 ton
Track gauge 600762 or 900mm
Traction force 5.74kN
Max traction force 7.36kN
Speed 7.5km/h
Dc voltage 250V
Motor power 6.5kW×2/ 7.5kw*2
Dimensions Length 2750mm
Width 9401082 or 1220mm
Height 1550mm
Wheelbase 850 mm
Wheel diameter Φ520 mm
working height of Pantograph 1800~2000mm
Min turn radius 6m
Control method Resistance or IGBT
Brake method Mechnical or hydraulic
