2.5 ton Battery Locomotive is a kind of locomotives which are designed for horizontal rail transport especially in mines and enclosed spaces, to the non-hazardous areas without explosion risks. The 2.5ton battery locomotive could pull about 25 ton ore
The 2.5 ton locomotive is applied of speed control of IGBT chopping wave type or resistence type. Its main features include: smooth starting, stable operation, small dimension, short wheel base,quick and reliable braking effect by means of braking shoes; simple structure for easy maintenance and reliable locomotive operation performance. It is an ideal type for transportation or transfer service in medium-small mines.
About the Traction: pull about 25ton ores including the wagons, the operating slope not excees the 3‰
Product Name: 2.5 ton underground mining battery locomotive |
Fuel Type: Electric |
Brand Name: YuTong |
Traction mode power: 3.5x1 |
Dimensions (L x W x H) (mm): 2360*914*1550mm |
Speed (km/h): 4.54km/h |
Application: Mining; Subway ,Tunnel Locomotive |
Rail gauge: 600/762/900mm |
Place of Origin: Xiangtan, China (Mainland) |
Rated voltage: 48V |
Advantages: Strong traction force |
Braking type: Mechanical and Electric |
Service: OEM/ODM |
Speed control: Resistor or AC or IGBT |
Video of our 2.5ton underground locomotive
