5 Ton Underground Mining Battery Locomotive

The 5 ton battery locomotive with small size short wheelbase small and flexible fast and reliable brake simple structure easy to repair suitable for roadway and small mine transportation and small and medium-sized mines.

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
The 5 ton battery locomotive with small size, short wheelbase, small and flexible, fast and reliable brake, simple structure, easy to repair, suitable for roadway and small mine transportation and small and medium-sized mines.The length of the entire mining locomotive is only 1.66 meters, which is directly below the cage.
Special design of the gearbox: The self-developed three-stage gearbox design is small in size and large in speed ratio, which improves the traction of the entire mining locomotive.

About us:
Our factory has been specialized in producing locomotives and spare parts since 1980.We have advanced technology and equipment, also with strong R&D ability
Our technician has more than 40 year’s professional working experience.
Locomotives are exported throughout the world. Main market: Norway, Turkey, USA,Canada,
Australia, Brazil, Uruguay, Iran, Philippines, Thailand, India, etc.
We could also provide online service to teach you how to operate and maintain the locomotive.

Operation Video:


Hot Tags: 5 ton underground mining battery locomotive China manufacturers suppliers factory customized price

←8 Ton Underground Mining Battery Locomotive

3.5 Ton underground mining battery locomotive→

Related Products
Model CTY5/6、7、9G(B)
Total-weight 5t
Track gague 500、600、762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 920、1082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter Φ520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic
