The working rated voltage of this 6 Ton Underground Mining Trolley Locomotive is 250V. Equipped of two traction motors with 18KW, two-stage driving of spur gear and bevel pinion. It has the advantages of strong traction, suitable for the undergound m
The working rated voltage of this 6 Ton Underground Mining Trolley Locomotive is 250V. Equipped of two traction motors with 18KW, two-stage driving of spur gear and bevel pinion. It has the advantages of strong traction, suitable for the undergound mines without gas exist.
The trolley locomotive consist of Mechanical part, running device, braking device, sanding device, cab, buffer, electrical part.
Operation Video
|
6ton Trolley Locomotive |
|||
|
Model |
CJY6/6、7、9G(B)(P) |
||
|
Adhesive / total weight (t) |
6t |
||
|
Track gauge (mm) |
600、762 or 900mm |
||
|
Traction |
11.94kN |
||
|
Max. Traction (KN) |
14.7kN |
||
|
Speed |
10km/h |
||
|
Direct Voltage |
250V |
550V |
|
|
motor power |
18Kw×2 |
||
|
Dimensions |
Length |
4430mm |
|
|
Width |
1050、1212 or 1350mm |
||
|
Height |
1600mm |
||
|
Wheel Base |
1150mm |
||
|
Wheel Diameter |
Φ680mm |
||
|
Operational height of current-controller |
2000~2400mm |
||
|
Min Curve radius (m) |
7m |
||
|
Controller |
Resistance or IGBT |
||
|
Braking method |
Mechanical Brake |
||
