Smaller Dumper Truck for Mining Transportation

The four-dump truck has a compact structure. Through the design of the cab (front part) suspension frame cargo compartment lifting mechanism etc.the structure is compact the turning radius is small and it is extremely flexible.The whole vehic

CJY10 Ton Underground Mining Trolley Locomotive

The four-dump truck has a compact structure. Through the design of the cab (front part) suspension frame cargo compartment lifting mechanism etc. the structure is compact the turning radius is small and it is extremely flexible.The whole vehicle is based on the design concept of mining vehicles and is scientifically and reasonably configured.This Mining Dump Truck is usually for underground or on ground transportation of ores with the advantages of good passability good safety strong power and strong carrying capacity.
It ususally used with the mucking machine together.
Advantage please click:
Dumper Truck advantages

Video



Shipment and site details





shipment and site 7.jpg



Product specification table

Model4TON5 Ton6 Ton8 Ton10 Ton12 Ton14 Ton16 Ton
Engine power63HP63HP42KW95HP95HP110HP130HP160HP
Axle modelFrount axle 2040Front axle 1069Front axle 1069Front axle 1098Front axle LN1098Front axle 1098Front axle 1098Front axle LN153
Axle modelRear axle IsuzuBack axle 1069Back axle 1069Back axle 1098Front axle LN1098Back axle 1098Back axle 1098Front axle LN153
Dimensions of carriage 2400*1500*4502800*1600*6002850*1600*5003000*1800*6003200*1800*6003400*2000*7003500*2000*8003900*2200*800
Carriage thicknessBottom 6 side 5Bottom 8 side 6Bottom 8 side 5Bottom 8 side 6Bottom 8 side 6Bottom 8 side 6Bottom 8 side 6Bottom 12 side 8
Tyre model700-16 mining tyre(Rear single wheel)700-16 mining tyre(Rear two wheels)700-16 mining tyre750-16 mining tyre750-16 mining tyre750-16 mining tyre825-16 mining tyre900-20 mining tyre
Hydraulic cylinder model110*900115*900115*1000115*1200115*1200115*1200130*1300130*1200
Steering methodHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steeringHydraulic steering gear steering
Exhaust gas treatmentWater treatmentWater treatmentWater treatmentWater treatmentWater treatmentWater treatmentWater treatmentWater treatment
Driving styleLeft-hand driveLeft-hand driveLeft-hand driveLeft-hand driveLeft-hand driveLeft-hand driveLeft-hand driveLeft-hand drive
CabSimple roofSimple roofSimple roofSimple roofSimple roofSimple roofSimple roofSimple roof
Dimensions4000*1500*13004300*1850*16004600*1630*15004700*1800*16504900*1800*16505150*2000*17005250*2000*19005800*2250*1990
Man-machine height1.8m1.8m1.9M1.9M1.9M1.9M2.1M2.2M
Gear modeGear shiftGear shiftGear shiftGear shiftGear shiftGear shiftGear shiftGear shift
Load capacity4 Ton 5 Ton 6 Ton8 Ton10 Ton12 Ton14 Ton16 Ton
