ZQ-18-5 18KW DC Traction Motor For Mining Locomotive

ZQ-18-5 18kw Dc traction motor is used on the china 6 ton trolley locomotive.

CJY10 Ton Underground Mining Trolley Locomotive

ZQ-18-5 Mining general type DC traction motor for locomotive (Used on 6 ton trolley locomotive)

The motor is applied as the driving motor of mining trolley locomotive of Model CJY6-6.7.9/250(V). It has the advantages of excellent performance and reliable product quality. It is designed with applicable technique and has features of stable performance long service life and convenient inspection and maintenance.

Specifications


Motor Power 18Kw
Voltage 250V
Current 83.5A
Rotating speed 1368r/min
Max Current 167A
Max Rotating 2736r/min
Structural type Horizontal
Working rating S2-60MIN
Excitation mode Excitation
Insulation grade F
Type of cooling IC40
Weight 322KG



1.1 Main uses

   ZQ-18-5 mine general DC traction motor is suitable for general mine underground environment conditions and it is for CJ6 / 250 type DC wire mine mine electric locomotive as driving motor.

1.2 Scope of application

     The motor should be able to operate normally under the following environmental conditions:

       a The altitude does not exceed 2000m;

       b. The maximum temperature of the air in the shade is not more than 40 ℃ and the minimum air temperature is not less than -25 ℃;

       c The average maximum relative humidity of the wettest month is not higher than 90% (the average monthly minimum temperature of the same month is not higher than 25 ℃);

       d The random vehicle runs under general mine conditions and there must be no enough gas and dust around it to cause explosion.
