ZQ-24 DC Traction Motor For 10 Ton Trolley Locomotive

The motor is applied as the traction motor of 10 ton mining trolley locomotive of first-stage driving (once of speed variation) Octagonal cast steel housing, trolley type suspension mode and nylon bearing are used on this motor. As an ideal motor for

CJY10 Ton Underground Mining Trolley Locomotive

The ZQ-24 DC motor is applied as the traction motor of 10 ton mining trolley locomotive of first-stage driving (once of speed variation) Octagonal cast steel housing, trolley type suspension mode and nylon bearing are used on this motor. As an ideal motor for small-tonnage mining trolley locomotive, it is of features of strong traction force, high overload ability, reliable operation capability and convenient maintenance.

Specifications:

Rated power: 24 kW

Rated voltage: 550 V

Rated current: 50.5 A

Rated speed: 600 r / min

Maximum speed: 1400 r / min

Maximum voltage: 660 V

Maximum current: 101 A

Excitation mode: series excitation

Insulation class: F Or H

Protection type: IP43

Mass: 545 kg

Factory Video



motors 1.jpg

motors 2.jpg

motors 3.jpg

motors 4.jpg

motors 5.jpg

motors 6.jpg

motors 7.jpg

shipment and site 18.jpg



Hot Tags: DC motor  |   traction motor  |   battery locomotive  |   trolley locomotive  |

Specification Table

Motor Power 20.6Kw
Voltage 250V
Current 95A
Rotating speed 600r/min
Max Current 190A
Max Rotating 1400r/min
Structural type Horizontal
Working rating S2-60MIN
Excitation mode excitation
Insulation grade F or H
Type of cooling IC40
Weight 525KG

ZQ-24 DC Traction Motor For 10 Ton Trolley Locomotive(图1)
ZQ-24 DC Traction Motor For 10 Ton Trolley Locomotive(图2)
