140V440ah Lead-acid Battery Device For 8 Ton Locomotive

140V440ah lead-acid battery device is applied in the China 8 ton battery locomotive, the model is CTY8/140V. The voltage is 140, the capacity is 440ah.

CJY10 Ton Underground Mining Trolley Locomotive

140V440ah lead-acid battery device for 8 ton 140V locomotive

140V440AH lead-acid battery devide is made up of 70 units 2 Voltage 440ah cells.

Outline dimensions:2700*1050*570

Attention of Lead-acid battery



During the loading and unloading of the battery, it should be handled with care to prevent it from being overturned and rolled.

Storage

1. It should be stored in a dry, clean and well-ventilated warehouse with a room temperature of 5-40°C.

2. Avoid contact with any liquids and harmful substances, and do not fall into any metal impurities.

3. Do not put it upside down, lie down, or be subjected to any mechanical shock or heavy pressure.

4.Must not be placed with alkaline substances.

5.The storage period from factory to use shall not exceed two years
