Narrow Gauge Trolley Locomotive

Narrow gauge trolley locomotive with durable performance for sale. We could customized locomotive according your different mine environment. Our factory has exported lots of locomotive to South America and Europe. Hoping to become your stable partner

CJY10 Ton Underground Mining Trolley Locomotive

Narrow gauge trolley locomotive with durable performance for sale. We could customized locomotive according your different mine environment. Our factory has exported lots of locomotive to South America and Europe. Hoping to become your stable partner in China.



Product Name: narrow gauge trolley locomotive

Fuel Type: Electric

Brand Name: HNYT

Traction mode power: 3.5x1

Dimensions (L x W x H) (mm): 2340*550*mm

Speed (km/h): 4.54km/h

Application: Mining; Subway ,Tunnel Locomotive

Rail gauge: 600/762/900mm

Place of Origin: Xiangtan, China (Mainland)

Rated voltage: 250V,100V

Advantages: Strong traction force

Braking type: Mechanical and Electric

Service: OEM/ODM

Speed control: Resistor or AC or IGBT



1.5ton Trolley Locomotive

Model

CJY1.5/6、7、9G(B)

Adhesive / total weight

1.5t

Track gauge

600、762 or 900mm

Traction

2.55kN

3.24kN

Max. Traction

3.68kN

Speed

4.54km/h

6.6km/h

Direct Voltage

100V

250V

motor power

3.5kW×1

6.5kW×1

Dimensions

Length

2340mm

2370mm

Width

950、1112 or 1250mm

Height

550mm

Wheel base

650mm

Wheel Diameter

Φ460mm

Operational height of current-controller

1600~2000mm

1800~2000mm

Min Curve radius

5m

Controller

Resistance or IGBT

Braking method

Mechanical Brake




Shipment and one site details

14t trolley locomotive 2.jpg







Technology Advantages
1. The vector control transformer, AC frequency change electric motor and new locomotive cabinet designed and developed by ourselves.
2. The products has good sticking, good overload ability, good climbing, safety braking, big traction and easy to operate
3. Human oriented design, the operation table of driver cab has speed/odometer display and locomotive running signal lamp.
4. Energy-saving, 25% energy saved compared to DC driving.
