15 Ton Battery Locomotive

The 15 ton battery locomotives are designed for horizontal rail transport especially in mines and enclosed spaces to the non-hazardous areas without explosion risks.

CJY10 Ton Underground Mining Trolley Locomotive

The main structure of 15 ton battery electric locomotive is divided into frame running part braking system traction drive system battery box operation control system etc.

It could choose the lithium battery as the power supply. Using the lithium battery power supply has the advtanges of safe and environmentally friendly with high quality and a cycle life of more than 4000 times which is 4-5 times than that of lead-acid batteries. Yutong lithium battery locomotive has good power performance long battery life and stable discharge. It only need to charged for 2 hours and run for 5 hours.

Operation Video of the 15 ton lithium battery




Hot Tags: 15 ton battery locomotive, China, manufacturers, suppliers, factory, customized, price



15ton Battery Locomotive

Adhesive / total weight (t)

15

Track gauge (mm)

600762 or 900

Traction (KN)

18.93

Max. Traction (KN)

36.78

Speed(km/h)

9.6

Max. Speed(km/h)

19.2

Battery Voltage (V)

256

Battery Capacity (Ah)

620

Power (KW)

30*2

Dimensions

Length(mm)

5200

Width(mm)

1400

Height(mm)

2140

Coupler height(mm)

320/430

Wheelbase (mm)

2200

Wheel diameter (mm)

680

Min Curve radius (m)

15

Controller

AC frequency conversion

Braking method

Mechanical Brake
Electrical Brake or Air Brake
