Home > Product > Battery locomotive > Flameproof Battery Locomotive
We have specialized in mining locomotive for many years, could offer battery powered mining locomotive with CE certification and factory price.
Product Description
Mine explosion proof diesel locomotive is a kind of driven, the vehicle with proof performance for containing flammable gas and coal dust and other dangerous places, traction, transport of mining locomotives, traction battery and then following the hydraulic transmission of a utility model traction. Mine explosion-proof drum & rail locomotive diesel engine series, is in line with the ideal of coal mine production safety transportation equipment. It is reasonable structure, compact, energy saving, high efficiency, easy operation and maintenance, frame lines motor vehicle, motorcycle batteries, compared does not need to set up traction power, do not need AC power and charging equipment.
We have specialized in mining locomotive for many years, could offer battery powered mining locomotive with CE certification and factory price.
Technical Specification
| Model | CTY3/6、7、9G(B) | ||
| Dead weight3 | t | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 2.55kN | ||
| Max traction force | 6.13kN | ||
| Speed | 4.54km/h | ||
| Battery device | Lithium battery | 51.2v 300ah | |
| Lead acid battery | 48V330AH | ||
| Motor power | 4.8kW×1 | ||
| Dimensions | Length | 2330mm | |
| width | 914、1076 or 1212mm | ||
| Height | 1550mm | ||
| Wheelbase | 650mm | ||
| Wheel diameter | Φ460mm | ||
| Min turn radius | 5m | ||
| Controlling way | Resistance or IGBT chopper | ||
| Brake way |
Mechanical brake |
||
