Battery locomotive are powered by batteries. After the battery pack on the locomotive is used to a certain extent it is removed and replaced with a good one. Therefore each battery locomotive must be equipped with 2-3 sets of battery packs.
10 ton Battery electric locomotive are powered by batteries there are leac-acid battery and lithium battery could be optional.
Type name : CTY10/6、7、9G（B）P
Application: This equipment is used for pulling up mine resources this equipment can also be used to haul mine trucks and transport raw coal ore gangue materials equipment personnel etc
It could be applied in minings or tunnel transporation.
Running Video
Technical Specification
| Model | CTY(L)10/6、7、9G | ||||||
| Dead-weight | 10 t | ||||||
| Track gague | 600、762 or 900mm | ||||||
| Tracktion force | 11.18kN | 12.83kN | |||||
| Speed | 6.2km/h | 7.5 km/h | 7.8 km/h | ||||
| Max traction | 19.62kN | ||||||
| Battery device | Voltage | 110V | 132V | 140V | 144V | ||
| Capacity | 440Ah | ||||||
| Motor power | 11kW×2 | 15kW×2 | |||||
| dimensions | Lenght | 4430mm | 4250mm | ||||
| Width | 1050、1212 or 1350mm | ||||||
| Height | 1600mm | 1600mm | |||||
| Wheel base | 1100mm | 1150mm | |||||
| Wheel diameter | Φ680mm | Φ680mm | Φ600mm | ||||
| Min turn radius | 7m | ||||||
| Controlling way | Resistence or IGBT or AC Converter | ||||||
| Brake way |
Mechnical brake or air brake |
||||||
