Application characteristics and working environment of bucket-tipping mine car
The bucket-tipping mine car is a narrow-gauge railway transportation vehicle for transporting coal ore ballast and other bulk materials in the mine. Generally it must be tract by a locomotive or a winch.
According to different structures and unloading methods they are divided into four categories: bucket-tipping mine car fixed mine car single-side curved rail dumping mine car and bottom-dumping mine car.
Operation video
Shipment and one site details
←No Information
Technical performance table of bucket-tipping mine car
| Volume | Nominal loading | Maximum loading | Gauge | Dimensions | Wheel base | Wheel diameter | Haule height | Traction | Minimum plane operating radius | Body weight | Unloading angle | |||
| Length | Width | High | ||||||||||||
| m3 | kg | kg | G mm | L mm | B mm | H mm | C mm | D mm | h mm | kN | m | kg | ° | |
| KFU0.75-6 | 0.75 | 1800 | 1800 | 600 | 1700 | 980 | 1250 | 600 | 300 | 320 | 60 | 9 | 740 | 40 |
| KFU1.0-6 | 1 | 2000 | 2500 | 600 | 1970 | 1070 | 1250 | 600 | 300 | 320 | 60 | 9 | 680 | 40 |
