This powerful diesel tricycle is designed to handle the tough demands of mining operations. It is powered by a 25hp motor that provides plenty of power for hauling heavy loads up steep inclines.
Powerful 4 ton mining diesel tricycle
This powerful diesel tricycle is designed to handle the tough demands of mining operations. It is powered by a 25hp motor that provides plenty of power for hauling heavy loads up steep inclines.
Shipment and site details
| Load capacity | 2 ton (flat slope) | 3 ton (flat slope) | 4 ton (flat slope) | 5 ton (flat slope) |
| Motor model | Changfa 18 hp | Changfa 22 hp | Changchai 25 hp | Changchai 32 hp |
| Start-up method | Electric start with hand crank function | Electric start with hand crank function | Electric start with hand crank function | Electric start with hand crank function |
| Steering Wheel | Power steering | Power steering | Power steering | turbo assisted steering wheel |
| Front tire | 500-14 | 500-14 | 600-14 | 600-14 |
| Back tire | 650-16 | 650-16 | 700-16mining tire | 750-16mining tire |
| Damping system | Weighted double shock absorption | Weighted double shock absorption | Weighted triple shock absorption | Weighted triple shock absorption |
| Carriage | 1.8*1.25*0.45m | 1.8*1.25*0.45m | 2.2*1.38*0.45m | 2.2*1.58*0.5 m |
| Dimensions | 3.4*1.1m*1.25m | 3.4*1.25m*1.25m | 3.8*1.4*1.3m | 2.4*1.58*0.55m |
| Thickness of carriage | Bottom5, side5 mm | Bottom5, side5 mm | Bottom5, side5 mm | Bottom5, side5 mm |
| Spring | Widened and thickened bow-shaped leaf spring | Widened and thickened bow-shaped leaf spring | 13 widened and thickened bow-shaped leaf springs | 13 widened and thickened bow-shaped leaf springs |
