YBVF-30Q AC Motor For Mine Explosion-Proof Battery Locomotive

The motor is applied as the driving motor of explosion-proof battery locomotive of Model CTY12-6.7.9/192 and suitable for working in workplace with methane and coal dust explosive mixture. As a substitute of DC traction motor this model has features

CJY10 Ton Underground Mining Trolley Locomotive

YBVF-30Q AC Motor is applied as the driving motor of explosion-proof battery locomotive of Model CTY12-6.7.9/192 and suitable for working in workplace with methane and coal dust explosive mixture.

The motor adopts Class F or H insulation and the temperature rise limit (resistance method) of its stator winding is evaluated according to 155K.

When the motor is at an ambient temperature of 40°C or below the allowable temperature of the rolling bearing (thermometer method) should not exceed 95°C.

Specification

YBVF-15Q AC motors Model YBVF-30Q
Working rating S2-60min
Power kw 22
Voltage v 140
Current A 164
Frequency Hz 63
Speed of rotation r/min 1237
Insulation grade F or H
Level of protection Ip54
Weight kg 370
