YVF45Q AC Motor For 14 Ton Trolley Electric Locomotive

YVF45Q AC Motor is used on China 14 ton trolley electric locomotive the model type is CJY14/679GP. It has features of simple structure energy conservation maintenance-free smooth operation capability and high efficiency.

CJY10 Ton Underground Mining Trolley Locomotive


YVF45Q (380/220) Mining general type AC traction motor

The motor is applied as the driving motor of mining VF AC trolley locomotive of two-stage driving (twice of speed variation) of Model CJY14-6.7.9/550. It has features of simple structure energy conservation maintenance-free smooth operation capability and high efficiency.

Before installation and use the motor must be kept in a clean clean and ventilated place its temperature is not lower than 5 ℃ the relative humidity must not be higher than 75% and the storage place must not be corrosive gases such as acid alkali etc. Alkali storage battery etc. are placed in the same warehouse.

We are a professional manufacture of the mine locomotive DCAC motors we could design the motors according to your need.

电机1

1587974907(1)





Hot Tags: yvf45q ac motor for 14 ton trolley electric locomotive, China, manufacturers, suppliers, factory, customized, price

Specification



YVF45Q Ac Motor Model YVF-45Q
Working rating S2-60min
Power kw 45
Voltage v 380
Current A 87.6
Frequency Hz 50
Speed of rotation r/min 987
Insulation grade F or H
Level of protection Ip54
Weight kg 590
