YVF-22Q Ac Motor For 7 Ton Mine Trolley Locomotive

The YVF-8 motor is applied as the driving motor of mining VF AC trolley locomotive of first-stage driving (once of speed variation) of Model CJY7-6.7.9 and CJY10-6.7.9. It has features of simple structure energy conservation maintenance-free smooth

CJY10 Ton Underground Mining Trolley Locomotive

The YVF-8 motor is applied as the driving motor of mining VF AC trolley locomotive of first-stage driving (once of speed variation) of Model CJY7-6.7.9 and CJY10-6.7.9. It has features of simple structure energy conservation maintenance-free smooth operation capability and high efficiency.

Usage Notice

     The motor adopts Class F insulation and the temperature rise limit (resistance method) of its stator winding is evaluated according to 155K.

     When the motor is at an ambient temperature of 40°C or below the allowable temperature of the rolling bearing (thermometer method) should not exceed 95°C.

Technical Parameters

YVF-22Q Ac Motor Model YVF-22Q
Working rating S2-60min
Power kw 22
Voltage v 380
Current A 47.3
Frequency Hz 40.1
Speed of rotation r/min 594
Insulation grade F or H
Level of protection Ip54
Weight kg 490
