5 Ton Flameproof Battery Electric Locomotive

CJY10 Ton Underground Mining Trolley Locomotive

    The 5 ton explosion-proof battery locomotive is widely used in mines that with gas. The locomotive adopts the IGBT controller or AC controller, which is easy to operate. It could pull about 50 ton ores at the slope of 3‰ , it will be a good choice for small or middle mines.

The quality of the our locomotive is in full compliance with the national standard requirements by using high-quality steel plates.

Strict assembly technology ensures that the locomotive leather is durable and reliable.

Special rust removal process on the surface plus multi-layer anti-corrosion coating, more anti-corrosion, suitable for

 high-corrosion and high-humidity environment in underground.

Operation Video


Shipment and one site details

5t battery locomotive 1.jpg









 Technical specification table

5 Ton Flameproof Battery Electric Locomotive(图1) Model CTY5/679G(B)
Total-weight 5t
Track gague 500600762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 9201082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter Φ520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic


5t battery locomotive 2.jpg

shipment and site 11.jpg
