3 Ton Battery Powered Mine Locomotive

The engine casing of our locomotive is processed by seamless steel tubes, specially developed for mine conditions, resistance to moisture and earthquakes.

CJY10 Ton Underground Mining Trolley Locomotive

Product Advantage

The engine casing is processed by seamless steel tubes, specially developed for mine conditions, resistance to moisture and earthquakes.

The steel wheel is cast in manganese steel, wear resistant and durable.

We have devoted ourselves to mining locomotive for many years, could offer battery powered mining locomotive with good mobility and factory price.

Quick information of 3 ton battery locomotive
Motor powe: 4.5kw*1
Battery Voltage: 48V330AH
Track gauge: 500.600.762 or 900


Locomotive Avantage Please Click: Locomotive Advantages.

Operation video


Shipment and one site details

2.5t battery locomotive 2.jpg

shipment and site 8.jpg

shipment and site 10.jpg

shipment and site 6.jpg







Technical Specification

Model CTY3/6、7、9G(B)
Dead weight 3t
Track gauge 600、762 or 900mm
Traction force 2.55kN
Max traction force 6.13kN
Speed 4.54km/h
Battery device Lithium battery 51.2v 300ah
Lead acid battery 48V330AH
Motor power 4.5kW×1
Dimensions Length 2330mm
width 914、1076 or 1212mm
Height 1550mm
Wheelbase 650mm
Wheel diameter Φ460mm
Min turn radius 5m
Controlling way Resistance or IGBT chopper
Brake way Mechanical brake
