CJY10 Ton Underground Mining Trolley Locomotive

Cjy 10Ton trolley locomotive could be used in middle or big mine, it has the advantages of big traction, easy to operate.

CJY10 Ton Underground Mining Trolley Locomotive
This 10ton trolley locomotive has four options: normal type thicken lateral plate type added sails type and two- motors type. The working rated voltages include 250V and 550V. Main features include: short wheel base and high stiffness of vehicle body. With application of new-type buffer the shockproof performance is good with big cushion angle.

Locomotive Avantage Please ClickLocomotive Advantages.

Operation Video



Hot Tags:

10ton Trolley Locomotive

Model

CJY10/6、7、9G(B)(P)

Adhesive / total weight (t)

10t

Track gauge (mm)

600、762 or 900mm

Traction

13.05kN

18.93kN

Max. Traction (KN)

24.5kN

Speed

11km/h

Direct Voltage

250V

550V

motor power

24Kw×2

30kW×2

Dimensions

Length

4550mm

Width

1050、1212 or 1350mm

Height

1600mm

Wheel base

1100、1220mm

Wheel Diameter

Φ680mm

Operational height of current-controller

1800~2200mm、2000~2400mm

Min Curve radius (m)

7、10m

Controller

Resistance or IGBT

Braking method

Mechanical Brake

CJY10 Ton Underground Mining Trolley Locomotive(图1)
