7 Ton Underground Mining Trolley Locomotive

CJY10 Ton Underground Mining Trolley Locomotive

The 7 Ton Underground Mining trolley locomotive is mainly used for the no-gas mine,

level one, level two gas mine and underground mine  with fresh wind flow.

Quick information of this 7ton trolley locomotive

Dead-weight :7 ton

Voltage :250 or 550V

Motor Power : 21x2 or 24kw x2

Pull traction(ton) : 70ton ores.


Locomotive Avantage Please ClickLocomotive Advantages.

Operation video


Shipment and one site details

7o10t trolley locomotive 2 s.jpg









7ton Trolley Locomotive

Model

CJY7/6、7、9G(B)(P)

Adhesive / total weight (t)

7t

Track gauge (mm)

600、762 or 900mm

Traction

13.05kN

15.09kN

Max. Traction (KN)

17.2kN

Speed

11km/h

Direct Voltage

250V

550V

motor power

21Kw×2

24kW×2

Dimensions

Length

4550mm

Width

1050、1212 or 1350mm

Height

1600mm

Wheel Base

1100mm

Wheel Diameter

Φ680mm

Operational height of current-controller

1800~2200mm

Min Curve radius (m)

7m

Controller

Resistance or IGBT

Braking method

Mechanical Brake



7o10t trolley locomotive 2 s.jpg

shipment and site 16.jpg
