The Z-17 Electric rock loader can be used in the field of metal mines(Gas free) drifting ore loading especially in some dangerous place which have the advantages of safer working environment enhancement in efficiency enhancement in integrated effects.
Product Desc
The Z-17 Electric rock loader can be used in the field of me
It have normal type and remote type can be choosed.
Operation Video
Shipment and one site details
Specification
| Model | Z-17AW | Z-20AW | Z-30AW | ZQ-26 | ||
| Loading capacity m3/h | 20-30 | 30-40 | 50-60 | 40-50 | ||
| Loading area m3 | 0.17 | 0-20 | 0.3 | 0.26 | ||
| Loading width m | 1.7 | 2 | 2.2 | 2.7 | ||
| Track gauge mm | 500600762 or 900 | |||||
| Power | Motor | Motor | Motor | Wind motor | ||
| Walking power kw | 10.5 | 10.5 | 15 | 10.5 | ||
| Lifting bucket power KW | 10.5 | 13 | 15 | 15 | ||
| Unloading height mm | 10.5 | 1360 | 1370 | 1250 | ||
| Dimension mm | Length | 2120 | 2480 | 2620 | 2440 | |
| Width | 1011 | 1380 | 1320 | 1380 | ||
| Height | 1920 | 1460 | 1545 | 1500 | ||
| Weight | 3760 | 3700 | 4600 | 2700 | ||
