Zq-13 Pneumatic Ore Mucking Machine

Zq-13 Pneumatic Ore Mucking Machine is a machine that loads ore or rock in a horizontal or gently inclined tunnel.

CJY10 Ton Underground Mining Trolley Locomotive

Zq-13 Pneumatic Ore Mucking Machine is a machine that loads ore or rock in a horizontal or gently inclined tunnel. The advantage is that the work is flexible and reliable, and the productivity of rock loading is also high, which is suitable for geological exploration tunnels.

What should be paid attention to when parking the Zq-13 Pneumatic Ore Mucking Machine?

After the Zq-13 Pneumatic Ore Mucking Machine finished its work, it needs to stop running. There are some matters that need to be paid attention to. Here, we will summarize the matters needing attention when the rock loader is out of service.

1. It is forbidden to use the steering rod and joystick as handrails to load the rock machine up and down.

2. The rock loader should be parked where the floor of the roadway is relatively flat as much as possible. When it must be parked on a slope, measures to prevent sliding should be taken.

3. After the rock loading is completed, the rock loading machine backs away to a safe place 50m away from the front.

4. Do a good job of equipment operation records and on-site shift records.

5. Before shooting head-on, raise the bucket of the rock loader to cover the lighting, pin the travel switch, cut off the power supply, turn the handle of the master switch to the stop position, and lock it with a safety lock. After shooting, put the bucket on the ground in time .

The correct use method can not only improve the working efficiency of the rock loader, but also effectively protect the Zq-13 Pneumatic Ore Mucking Machine, so we must follow the above methods when using it.




Shipment and one site details








1Bucket volume0.13m3
2Technical productivity25m3/h
3 Walking motor
3.1Power9kw x 1each
3.2Speed2500r/min
3.3Maximum air consumption11.7m3/min x 2each
3.4Working air pressure4.21-7.03kg/cm2
4 Hoist bucket motor
4.1Power9kw
4.2Speed2500r/min
4.3Maximum air consumption15.6m3/min
4.4Working Air pressure4.21-7.03kg/cm2
5Walking speed1.4m/s
6External dimensions
6.1the length1860mm
6.1.1Put down the bucket1850mm
6.1.2Height1300mm
6.1.3Lifting the bucket1950mm
