Wheel pneumatic rock loader

Pneumatic Shovel Wheel Type Rock Loader with compressed -air rock shovel, it has feature of follows

CJY10 Ton Underground Mining Trolley Locomotive

Pneumatic Shovel Wheel Type Rock Loader with compressed -air rock shovel, it has feature of follows:

Dependable Rock loading;

Simple, self centred controls for easy and safe operation;

Low centre of gravity;

Easy swinging of upper deck for side digging;

Wide tread wheels with deep flanges for extra stability;

Power swing, as an option, for virtual pinpoint control of bucket position.



Shipment and one site details









ModelModel
Loading capacity100m3/h70m3/h
Loading area0.45m30.3m3
Walking power20HP*29kw*2
Maximum air consumption17.6m3/min*217.6 m3 / min×2
Working pressure4.21-7.03kg/cm2(60-100psi)4.21-7.03kg/cm2(60-100psi)
Rising motor25HP*215kw
Maximum air consumption20m3/min20m3/min
Working pressure4.21-7.03kg/cm2(60-100psi)4.21-7.03kg/cm2(60-100psi)
Walking speed1.81m/s1.81m/s
Tire typesolid tiresolid tire
Rising height2600mm2380mm
dump width1200mm1200mm
Unloading height1500mm1400mm
Unloading distance457mm450mm
Machine length2800mm2600mm
