The ZQW-13 Pneumatic Wheel Type Rock Loader is a compact and maneuverable wheel-type rock loader that combines high mobility with powerful loading capabilities.Its easy operation and simple maintenance make it ideal for various applications, including construction, mining, and quarrying.
The ZQW-13 Pneumatic Wheel Type Rock Loader is a compact and maneuverable wheel-type rock loader that combines high mobility with powerful loading capabilities.
Its easy operation and simple maintenance make it ideal for various applications, including construction, mining, and quarrying.
Shipment and one site details
| model parameters | ZQ-13 | ZQ-17 | ZQ-26 | ZQW-13 | QZ-17 | QZ-30 | CJQ-15 | CJQ-20 |
| Laneway width*height(m*m) | 1.8*2.5 | 1.7*2 | 2.2*2.5 | 2*2.2 | 1.7*2 | 2.2*2.5 | 1.7*2 | 2*2.2 |
| gauge(mm) | 600/762/900 | |||||||
| Loading Width (mm) | 1910 | 2700 | No limit | No limit | 1050 | |||
| Loading Height (mm) | 1975 | 2240 | 1830 | 1975 | 2380 | 1750 | 1050 | |
| Unloading Height (mm) | 1250 | 1260 | 1250 | 1250 | 1150 | 1450 | 1900 | 380 |
| Bucket Volume (m3) | 0.13 | 0.17 | 0.26 | 0.13 | 0.17 | 0.30 | 0.15 | 0.20 |
| Length (mm) | 2230 | 2230 | 2440 | 1900 | 2250 | 2600 | 2300 | 2690 |
| Width (mm) | 1200 | 1360 | 1380 | 800 | 1490 | 1650 | 1490 | 1630 |
| Height (mm) | 1200 | 1390 | 1500 | 1230 | 1500 | 1500 | 1380 | 1380 |
| Walking motor power (kw) | 9 | 11 | 11 | 9 | 9 | 9 | 9 | 9 |
| Rising motor power (kw) | 9 | 15 | 15 | 15 | 15 | 15 | 12 | 12 |
| Device Totally weight (kg) | 1950 | 2700 | 2700 | 2000 | 3200 | 4200 | 3100 | 3350 |
| Working pressure (mpa) | 0.45-0.86 | 0.45-0.7 | 0.45-0.7 | 0.48-0.86 | 0.44-0.67 | 0.44-0.67 | 0.42-0.7 | 0.5-0.7 |
