CJY14 Ton Trolley Locomotive

Cjy 14ton mining trolley locomotive has 3 types of track gague-600762 or 900.And the voltage could be 250V or 550V. It could pull about 140ton ores.

CJY10 Ton Underground Mining Trolley Locomotive

The 14ton Trolley locomotives are designed for horizontal rail transport especially in mines and enclosed spaces to the non-hazardous areas without explosion risks. They can work on slopes of rail tracks to 35‰ with track gauge from 500 to 1060 mm at ambient temperatures from -10 to 40 °C.

Video of 14ton trolley locomotive:




Shipment and one site details

14t trolley locomotive 1.jpg








What should i consult before i make the quotation?

The Voltage of the trolley locomotive usually it will be 250V or 550V

The track guage usually it will be 600、762or 900 if you want special track guague we also could provide it.

The control way we got 3 type of control way the resistence The IGBT and the AC control.

The brake method for 14 ton brake method we have 2 types one is mechnical and the other is air brake.

For the differenct of the different configuration requirements please click the red words:Locomotive Advantages


Specifactions of trolley locomotive:

14ton Trolley Locomomtive

Model

CJY14/6、7、9G(B)(P)

Adhesive / total weight

14t

Track gauge

600、762 or 900mm

Traction

26.68kN

Max. Traction

34.3kN

Speed

12.87km/h

Direct Voltage

250V

550V

motor power

52kW×2

Dimensions

Length

4800mm

Width

1060、1222 or 1360mm

Height

1700mm

Wheel Base

1700mm

Wheel Diameter

Φ760mm

Operational height of current-controller

2000~3200mm

Min Curve radius

12m

Controller

Resistance or IGBT

Braking method

Air Mechanical Brake
