Mining Lithium Battery Locomotive applied the lithium battery as its power supply.With the lithium battery, the battery no need to maintain,and the charging time only for 2-3 hours.
Mining Lithium Battery Locomotive applied the lithium battery as its power supply.
With the lithium battery, the locomotive has the belowe advantages.
1、Quick Charge, 2-3 hours.
2、Car Bms management system, Overcharge protection, over discharge protection, over current protection, short circuit protection and temperature protection to ensure high effective running.
3、Maintenece-free, no need to add bath solution, more environment friendly. labor-cost saving.
4、Long service life up to 5-8 years.
Below is the operation video of the Mining Lithium Battery Locomotive, Underground lithium powered battery locomotive
←5 Ton Lithium Battery Locomotive
No Information→
Specifactions:
|
2.5ton Battery Locomotive |
|||
|
|
Specifications |
||
|
Adhesive / total weight (t) |
2.5 |
||
|
Track gauge (mm) |
600,762 or 900 |
||
|
Traction (KN) |
2.55 |
||
|
Max. Traction (KN) |
6.13 |
||
|
Speed |
4.54 |
||
|
Battery Voltage (V) |
48 |
||
|
Battery Capacity (Ah) |
330 |
||
|
Power (KW) |
3.5*1 |
||
|
Dimensions |
Length(mm) |
2360 |
|
|
Width(mm) |
914,1076 or 1214 |
||
|
Height(mm) |
1550 |
||
|
Wheelbase (mm) |
650 |
||
|
Wheel diameter (mm) |
460 |
||
|
Min Curve radius (m) |
5 |
||
|
Controller |
Resistance or IGBT |
||
|
Braking method |
Mechanical Brake |
||
