10 Ton Lithium Battery Locomotive

CTY10/6GB refer to the mining 10 Ton electric battery locomotive and the track gauge be 600mm the loading capacity could up to 80-90 Ton ores.

CJY10 Ton Underground Mining Trolley Locomotive
1. Product Model explanation and loading capacity
CTY10/6GB refer to the mining 10 Ton electric battery locomotive and the track gauge be 600mm the loading capacity could up to 80-90 Ton ores.

2. Questions before inquiry
Controller: Cam Chopping or frequency conversion controller
Track gauge: 600.762.900 different track gauge could design as required
Brake method: Mechnical or Air brake


Locomotive Avantage Please ClickLocomotive Advantages.

Operation video


Hot Tags: 10 Ton Lithium Battery Locomotive, China, manufacturers, suppliers, factory, customized, price
Technical Specification

Model CTY(L)10/6、7、9G
Dead-weight 10 t
Track gague 600、762 or 900mm
Tracktion force 11.18kN 12.83kN
Speed 6.2km/h 7.5 km/h 7.8 km/h
Max traction 19.62kN
Battery device Voltage 110V 132V 140V 144V
Capacity 440Ah
Motor power 11kW×2 15kW×2
dimensions Lenght 4430mm 4250mm
Width 1050、1212 or 1350mm
Height 1600mm 1600mm
Wheel base 1100mm 1150mm
Wheel diameter Φ680mm Φ680mm Φ600mm
Min turn radius 7m
Controlling way Resistence or IGBT or AC Converter
Brake way Mechnical brake or air brake
